Schneider Electric ZB5RTC2 Pushbutton Transmitter 22mm

Product Description

The SCHNEIDER ELECTRIC ZB5RTC2 is a wireless, batteryless pushbutton switch transmitter designed for use with 40mm extended mushroom head pushbutton operators. Built for the Harmony XB5R plastic and XB4R metal 22mm pushbutton platform, this transmitter converts a mechanical button press into a wireless control signal without requiring a battery or external power source at the operator. The round, non-illuminated black operator is constructed from plastic and weighs 0.15 pounds. Electricians and automation technicians install this component as part of a wireless machine control or process control station where running control wiring to the operator location is impractical or cost-prohibitive.

This transmitter is suited for light industrial, commercial, and manufacturing applications where wireless pushbutton control stations are needed. The extended mushroom head profile is commonly chosen for emergency-stop-style or high-visibility control points. The batteryless, wireless design eliminates wiring runs between the operator and the control panel, reducing installation time on new builds and retrofit projects alike. It is installed by licensed electricians or qualified automation technicians working on machine control, conveyor, or process equipment panels.

Key Features

• Wireless and batteryless operation -- no wiring or battery required at the operator location
• Extended mushroom head, round button profile for high-visibility control applications
• Non-illuminated black operator for standard control station configurations
• Compatible with the Harmony XB5R and XB4R 22mm pushbutton platform
• Plastic construction, lightweight at 0.15 pounds
• Package quantity of 1 for single-unit replacement or new installation

Compatibility

Designed for use with 40mm mushroom head pushbuttons on the Harmony XB5R Plastic and XB4R Metal Wireless/Batteryless 22mm pushbutton platform.

Installation Notes

Installation should be performed by a licensed electrician or qualified automation technician in accordance with applicable NEC requirements and the equipment manufacturer's instructions. De-energize and lock out the control panel before replacing or installing any pushbutton operator components. Verify that the transmitter and receiver pairing procedure is completed per the system documentation before returning the equipment to service. Do not modify the operator housing or attempt to use this transmitter outside of its rated platform.
