Schneider Electric ZB5AW7A3741 Push-button Switch 22mm

Product Description

The SCHNEIDER ELECTRIC ZB5AW7A3741 is an illuminated, momentary push-button switch designed for industrial control panel applications. It features a 22 mm mounting hole diameter and a flush-mounted rectangular operator in chromium-plated metal bezel construction. The switch uses an LED lamp for operator illumination and follows an On-Off switch sequence with momentary actuation. Rated for NEMA 4X and 13 environments, it is built to resist shock and vibration, making it suitable for demanding service conditions. Licensed electricians and industrial control panel builders are the primary installers for this component.

This push-button switch is intended for use in industrial and commercial control panels where a flush-mount, illuminated momentary operator is required. The 22 mm mounting hole diameter is a widely used standard size in control panel construction. The switch is available with green or red push-button colors, allowing for visual status differentiation at the operator interface. It is appropriate for both new panel builds and replacement installations in existing enclosures that accept 22 mm operators.

Key Features

• 22 mm mounting hole diameter fits standard industrial control panel cutouts
• Momentary On-Off operation with LED illumination for operator feedback
• Flush rectangular push-button profile in green or red
• Chromium-plated metal bezel for durability and corrosion resistance
• Shock-resistant and vibration-resistant construction
• NEMA 4X and 13 rated for wet, dusty, and corrosive environments

Compatibility

Designed as an OEM-style replacement or new-installation momentary push-button switch for industrial control panels and enclosures accepting a standard 22 mm operator mounting hole.

Installation Notes

Installation should be performed by a licensed electrician in accordance with NEC requirements and applicable local codes. De-energize the control panel and verify zero voltage before beginning any switch replacement or installation. The 22 mm panel cutout must be clean and free of burrs to ensure proper seating of the chromium-plated bezel. Verify that the LED lamp voltage matches the control circuit voltage before completing the wiring terminations.
