Schneider Electric ZB4BZ079 Fixing Collar Harmony XB4

Product Description

The SCHNEIDER ELECTRIC ZB4BZ079 is a fixing collar designed for use with Harmony XB4 series pushbutton control stations. This accessory secures the control station body during panel installation, maintaining proper alignment and mechanical retention of the operator interface. Measuring 1.2 inches in length, 1.1 inches in width, and 0.9 inches in height, it is a compact hardware component weighing 0.01 pounds. Electricians and industrial control panel builders install this collar when assembling or servicing XB4-series operator interfaces mounted in enclosure cutouts.

This fixing collar is suited for industrial and commercial control panel applications where Harmony XB4 pushbutton operators are installed in standard panel cutouts. It is used during new panel builds and as a replacement part when the original collar is damaged or missing. The ZBZ010 is a noted compatible base unit for this collar. Installation typically occurs in machine control, motor starter, and process control enclosures.

Key Features

• Designed specifically as a fixing collar accessory for Harmony XB4 control station operators
• Compact form factor at 1.2 x 1.1 x 0.9 inches for standard panel cutout fitment
• Lightweight at 0.01 pounds, adding minimal mass to the assembly
• Sold individually, allowing single-unit replacement without excess inventory
• Compatible with ZBZ010 base unit as noted in product documentation

Compatibility

Designed for use with SCHNEIDER ELECTRIC Harmony XB4 series pushbutton control stations and the ZBZ010 base unit.

Installation Notes

Installation is performed by a qualified electrician or control panel technician. De-energize and lock out the control panel before servicing any operator interface components in accordance with NFPA 70E and applicable lockout/tagout procedures. The fixing collar is seated around the operator body and tightened into the panel cutout to secure the unit mechanically. Do not over-tighten or force the collar, as damage to the operator housing may result.
