Schneider Electric XALD04H7 Pushbutton Switch Enclosure

Product Description

The SCHNEIDER ELECTRIC XALD04H7 is a four-hole polycarbonate pushbutton switch enclosure rated for NEMA 13 and 4X environments. It is designed to house 22mm pushbutton operators, selector switches, pilot lights, and similar control devices used in industrial and commercial electrical control systems. The enclosure measures 5.5 inches in length, 2.7 inches in width, and 3 inches in height, providing a compact footprint for panel and surface mounting. Licensed electricians and industrial control technicians are the primary installers of this component. Polycarbonate construction provides impact resistance and chemical resistance suited to wet or oily service areas.

This enclosure is appropriate for use in factory automation, machine control stations, pump control panels, and similar applications where operators require direct access to multiple pushbutton or selector switch controls. The four pre-drilled 22mm holes accommodate standard 22mm operator hardware. The NEMA 4X and 13 ratings make it suitable for both washdown environments and locations where oil or coolant splash is a concern, spanning light industrial through heavy-duty manufacturing settings.

Key Features

• Four pre-drilled holes sized for standard 22mm control operators
• Polycarbonate construction offers impact resistance and corrosion resistance
• NEMA 13 and 4X dual rating covers oil-tight and watertight service conditions
• Compact body at 5.5 x 2.7 x 3 inches fits tight panel and surface-mount locations
• Lightweight at 0.62 pounds for easy positioning during installation

Compatibility

Designed as an OEM-style enclosure for standard 22mm pushbutton and selector switch operators used in industrial control panel assemblies.

Installation Notes

Installation should be performed by a licensed electrician in accordance with NFPA 70 (NEC) requirements for industrial control panels. De-energize and lock out the circuit before mounting or wiring any components inside the enclosure. Verify that the mounting surface is clean and flat to maintain the enclosure seal and preserve the NEMA rating. Do not over-tighten operator hardware, as polycarbonate threads can strip if excessive torque is applied.
