Schneider Electric V121 Enclosed Relay 24 VAC/DC 120 VAC

Product Description

The Schneider Electric V121 is an enclosed relay designed for various automation systems. This device operates at a voltage of 24 VAC/DC and 120 VAC. It can handle resistive loads of up to 20 Amps at 240 VAC and 8 Amps at 28 VDC.

• SPST configuration
• HOA switch for manual operation
• LED indicator for status monitoring

Product Highlights

The V121 relay is suitable for building automation, offering reliable performance across a temperature range of -40 to 55 degrees Celsius.

Product Information

Standard Information

• Brand: Schneider Electric
• Country of Origin: US

Technical Specifications

• Relay Type: Mechanical
• Maximum Switching Current: 20 A at 240 V AC
• Relay Coil Voltage: 120 V AC, 24 V AC, 24 V DC
• Operating Temperature: -40 to 55 °C
• Dimensions (LxWxH): 4.0 x 2.04 x 2.50 inches
• Product Certifications: UL
• Mounting Support: DIN rail, wall
