Schneider Electric TM241CE40R Square D Programmable Logic Controller 24 VDC M241

Product Description

The Schneider Electric TM241CE40R is a 24 VDC programmable logic controller from the Modicon M241 range, designed for demanding applications. This logic controller features 24 discrete and 8 fast inputs, along with 12 relay outputs, 4 transistor outputs, and 4 fast transistor outputs. It's suitable for various industrial automation tasks. The controller operates at a supply voltage of one hundred to two hundred forty volts AC. Its output voltage ranges from five to one hundred twenty-five volts DC, and it can handle up to two amps for relay outputs.

• Built-in USB port and dual non-isolated serial links
• Includes 8 MB program memory and 128 MB flash memory
• DIN rail mount compatible for easy installation

Product Highlights

This controller integrates advanced connectivity options and an intuitive screen design for seamless application development using EcoStruxure Machine Expert. The Modicon M241 controllers can improve productivity through efficient machine programming.

Product Information

Standard Information

• Brand: Schneider Electric
• Manufacturer: Square-D / Schneider

Technical Specifications

• MPN: TM241CE40R
• Product ID: 980676
• Dimensions: 190 mm width x 95 mm depth x 90 mm height
• Weight: 0.62 kg (1.37 lbs)
• Memory: 64 MB RAM, 8 MB program
• Temperature Range: -10 to 55 degrees Celsius
• Storage Temperature: -25 to 70 degrees Celsius
• Certifications: CE, IACS E10, RCM, CSA, CULus
