Schneider Electric RPF2BP7 Plug-in Relay 7500 Va 2CO

Product Description

The SCHNEIDER ELECTRIC RPF2BP7 is an electromechanical plug-in general purpose relay rated at 7,500 VA, designed for industrial and commercial control panel applications. It features a 2CO (double pole double throw) contact form and a coil voltage of 230 VAC. Contact ratings include 20 amps and 25 amps at 28 VDC, 3 amps at 250/277 VAC, and 30 amps at 250 VAC and 277 VAC. The plug-in terminal type allows for quick installation into compatible relay sockets without direct wire terminations. Licensed electricians and control panel technicians are the primary installers for this type of component.

The RPF2BP7 is suited for use in residential, commercial, and light industrial control circuits where reliable switching of loads across multiple poles is required. Typical applications include HVAC control panels, motor control circuits, lighting relay panels, and general automation wiring enclosures. The plug-in design makes it well-suited for installations where relay replacement frequency is a maintenance consideration.

Key Features

• 7,500 VA power rating for robust load-switching capability
• 2CO contact form provides two independent switching circuits in a single relay body
• Plug-in terminal type enables tool-free relay replacement in compatible sockets
• Coil voltage of 230 VAC matches common European and North American control circuit standards
• Contact ratings up to 30 amps at 250 VAC and 277 VAC for high-current load applications
• Meets CSA C22.2 No. 14, EN/IEC 61810-1, and UL 508 standards

Compatibility

Designed as an OEM-style plug-in replacement relay for use in compatible relay socket bases used in general purpose industrial and commercial control panel assemblies.

Installation Notes

Installation should be performed by a licensed electrician in accordance with NEC requirements for control circuit components. De-energize and lock out the control panel before inserting or removing the relay from its socket. Confirm the socket base is rated for the relay contact and coil specifications before seating the RPF2BP7. Do not exceed the published contact current ratings for any voltage configuration.
