Schneider Electric MF40-7043-501 Direct Coupled Actuator 35 in-lb.

Product Description

The Schneider Electric MF40-7043-501 is a direct coupled actuator with a torque rating of thirty-five inch-pounds. This actuator is designed for effective control in HVAC systems. It operates on twenty-four volts alternating current or direct current and has a power consumption of 5.9 volt-amperes.

• Direct mount to round or square damper shaft.
• True mechanical clockwise or counterclockwise spring return operation.
• Overload protection throughout rotation.

Product Highlights

This actuator features a visual position indicator, rugged die-cast housing, and operation under a wide range of conditions.

Product Information

Standard Information

• Brand: Schneider Electric
• Part #: MF40-7043-501

Technical Specifications

• Housing: NEMA 2, IP54
• Auxiliary Switch: 1 x SPDT
• Power Consumption: 24 VAC, 5.9 VA
• Operating Conditions: -22 F to 140 F (-30 C to 60 C)
• Electrical Connections: 3 ft. plenum cable with 1/2 in. conduit connector
• Rotation Limiting: Available
• Control Mode: Direct acting or reverse acting on proportional models
