Schneider Electric M9F12110 Miniature Circuit Breaker 10A D Curve

Product Description

Schneider Electric M9F12110 is a low voltage miniature circuit breaker (MCB). This 1P circuit breaker features a ten amp rated current and D tripping curve. It offers short circuit breaking capacity up to three kiloamperes at four hundred fifteen volts AC, meeting EN/IEC 60947-2 standards. The device is compliant with both industrial and residential standards, providing protection against electrical hazards for equipment and individuals.

• Rated current of ten amps
• Electrical endurance of up to ten thousand cycles
• Designed for OEMs and control panel builders

Product Highlights

Enhances safety by preventing overload, short circuits, and earth leakage. Its design includes easy DIN rail installation and features a fast closing mechanism.

Product Information

Standard Information

• Manufacturer: Schneider Electric
• Catalog Number: M9F12110

Technical Specifications

• Dimensions: Width 18mm, Height 81mm, Depth 72mm
• Weight: 0.12 kg
• Operating Voltage: 240 VAC
• Rated Insulation Voltage: 500 VAC
• Impulse Withstand Voltage: 6 kV
• Operating Temperature: -30°C to 70°C
• Storage Temperature: -40°C to 80°C
• IP Rating: IP20
• Pollution Degree: 3
• Overvoltage Category: IV
