Schneider Electric LUCD12FU Starter Control Unit

Product Description

The SCHNEIDER ELECTRIC LUCD12FU is a starter control unit designed as an accessory for compatible motor starter communication and function modules. This control unit provides the interface logic needed to operate and manage motor starter assemblies in industrial and commercial electrical control systems. It mounts directly to supported starter modules and enables control-circuit functionality within low-voltage motor control applications. Licensed electricians and industrial control technicians are the primary installers of this component. Key physical specs include overall dimensions of 4.1 inches height, 2.1 inches width, and 3.3 inches length, with a lightweight package weight of 0.32 pounds.

The LUCD12FU is intended for use in low-voltage motor control panel assemblies where compatible SCHNEIDER ELECTRIC starter modules are already installed. Typical install scenarios include industrial control panels, machine automation enclosures, and commercial building electrical systems requiring coordinated motor starter control. This unit is sold individually as a single-piece replacement or new-installation accessory.

Key Features

• Direct-mount starter control unit for compatible SCHNEIDER ELECTRIC function and communication modules
• Compact form factor: 4.1 inches height, 2.1 inches width, 3.3 inches length
• Lightweight at 0.32 pounds for straightforward panel integration
• Sold as a single-unit package, suitable for individual replacement or new installation
• Compatible with multiple SCHNEIDER ELECTRIC starter accessory modules including LUFC00, LUFDA01, LUFDA10, LUFDH11, LUFN, LUFV2, and LUFW10

Compatibility

The LUCD12FU is designed for use with the following SCHNEIDER ELECTRIC starter modules: LUFC00, LUFDA01, LUFDA10, LUFDH11, LUFN, LUFV2, and LUFW10.

Installation Notes

Installation should be performed by a licensed electrician familiar with low-voltage motor control panel work and applicable NEC requirements. De-energize the control panel and verify absence of voltage before handling or mounting this control unit. Follow the manufacturer wiring and mounting documentation for the specific starter module in use. Do not force-fit or modify the unit housing, as damage to the control interface may result in improper starter operation.
