Schneider Electric LUCB1XFU Starter Control Unit

Product Description

The SCHNEIDER ELECTRIC LUCB1XFU is a starter control unit designed to interface with compatible motor starter function modules in industrial and commercial electrical systems. This control unit serves as the command interface between the operator or control circuit and the starter module, enabling start, stop, and protection functions across the connected system. Weighing 0.32 pounds and measuring 4.1 inches in length, 3.3 inches in width, and 2.1 inches in height, it is a compact component suited for panel or enclosure mounting. Installation is typically performed by a licensed electrician familiar with motor control center assemblies and IEC-style starter components.

The LUCB1XFU is intended for use in motor control applications where a dedicated control unit is required to operate with SCHNEIDER ELECTRIC starter function modules. Compatible modules include the LUFC00, LUFDA01, LUFDA10, LUFDH11, LUFN, LUFV2, and LUFW10. These applications span commercial and light industrial environments where motor protection and control reliability are critical. This unit is a direct OEM-style replacement or spare component for existing installations using the specified module families.

Key Features

• Interfaces directly with LUFC00, LUFDA01, LUFDA10, LUFDH11, LUFN, LUFV2, and LUFW10 function modules
• Compact form factor at 4.1 x 3.3 x 2.1 inches for panel or enclosure integration
• Lightweight at 0.32 pounds, minimizing load on mounting hardware
• OEM-style replacement suitable for existing SCHNEIDER ELECTRIC starter module installations
• Single-unit packaging for straightforward stocking and replacement

Compatibility

The LUCB1XFU is designed for use with the following SCHNEIDER ELECTRIC starter function modules: LUFC00, LUFDA01, LUFDA10, LUFDH11, LUFN, LUFV2, and LUFW10.

Installation Notes

Installation should be performed by a qualified electrician in accordance with the NEC and any applicable local codes. De-energize and lock out the motor control circuit fully before removing or installing this control unit. Verify module compatibility against the existing starter assembly before installation. Do not force-fit the unit onto a module outside the specified compatible list, as improper mating can damage both components.
