Schneider Electric LUCB1XBL Starter Control Unit

Product Description

The SCHNEIDER ELECTRIC LUCB1XBL is a starter control unit designed for use with compatible Schneider Electric soft starter and motor control modules. It serves as the operator interface and command component within a motor starter assembly, allowing control signals to be routed through the system for start, stop, and fault-reset functions. Licensed electricians and industrial maintenance technicians install this unit as part of low-voltage motor control applications. At 0.29 pounds, it is a compact component suited for panel and enclosure-based installations where space and weight are considerations.

The LUCB1XBL is applied in residential, commercial, and light industrial electrical systems where Schneider Electric TeSys U motor starter platforms are in use. It connects to a range of communication and function modules within the TeSys U ecosystem, making it a common replacement component for maintenance and service work on existing motor control assemblies.

Key Features

• Functions as the control unit within compatible Schneider Electric starter assemblies
• Lightweight at 0.29 pounds for easy handling and panel installation
• Compatible with a broad range of Schneider Electric communication and function modules
• Sold individually with a minimum order quantity of one

Compatibility

Designed for use with the following Schneider Electric modules: ASILUFC5, ASILUFC51, LUFC00, LUFDA01, LUFDA10, LUFDH11, LUFN, LUFV2, LUFW10, LULC031, LULC033, LULC07, LULC08, LULC09, and LULC15.

Installation Notes

Installation should be performed by a qualified electrician in accordance with NEC requirements and the manufacturer's wiring diagrams. De-energize the motor control panel and verify absence of voltage before handling or replacing this control unit. Confirm module compatibility by cross-referencing the existing starter assembly part numbers against the compatibility list prior to installation.
