Schneider Electric LUCB18FU Starter Control Unit

Product Description

The SCHNEIDER ELECTRIC LUCB18FU is a starter control unit designed to interface with compatible motor starter communication and function modules. It serves as the control interface component within a modular starter assembly, providing the switching and signal logic that links the starter body to field-installed accessory modules. This unit is installed by licensed electricians and industrial controls technicians working on motor control systems in commercial and industrial panels. At 0.32 pounds, it is a compact component that fits within the modular starter architecture it was designed to support.

The LUCB18FU is intended for use in motor control center applications and industrial automation panels where modular starter assemblies are specified. It pairs with a defined set of communication and function modules, making it a targeted replacement or expansion component for existing starter configurations. Typical installation scenarios include motor branch circuit control in light industrial, commercial HVAC, and process equipment applications.

Key Features

• Modular starter control unit designed for direct pairing with compatible SCHNEIDER ELECTRIC function modules
• Compact form factor at 3.1 inches height, 4.1 inches width, and 2.1 inches length
• Lightweight at 0.32 pounds for easy handling during panel assembly
• Compatible with LUFC00, LUFDA01, LUFDA10, LUFDH11, LUFN, LUFV2, and LUFW10 modules
• Sold individually, one unit per package

Compatibility

The LUCB18FU is compatible with the following SCHNEIDER ELECTRIC modules: LUFC00, LUFDA01, LUFDA10, LUFDH11, LUFN, LUFV2, and LUFW10.

Installation Notes

Installation should be performed by a qualified electrician familiar with motor control equipment and applicable NEC requirements. De-energize and lock out the motor control center or panel before removing or installing any starter components. Verify module compatibility against the existing starter assembly before installation. Follow the manufacturer documentation for proper module mating and retention procedures.
