Schneider Electric LUCB18BL Starter Control Unit

Product Description

The Schneider Electric LUCB18BL is a starter control unit designed for use with compatible TeSys U motor starter base units and communication modules. This component serves as the control interface within a motor starter assembly, managing the operational logic that governs motor start, stop, and protection functions. It is a direct accessory intended for integration into an existing starter platform rather than a standalone device. Electricians and industrial maintenance technicians install this unit as part of a modular starter system in commercial and industrial electrical panels and motor control centers.

The LUCB18BL is suited for motor control applications in commercial and industrial settings where modular starter assemblies are used. It connects with a defined set of function modules and communication interfaces within the TeSys U product family. Typical installation scenarios include motor control centers, machinery control panels, and automated process equipment where motor protection and control logic must be field-configured or replaced without removing the entire starter assembly.

Key Features

• Modular control unit designed to integrate with TeSys U compatible function and communication modules
• Compatible with a broad range of communication and function modules including LUFC00, LUFDA01, LUFDA10, LUFDH11, LUFN, LUFV2, LUFW10, LULC031, LULC033, LULC07, LULC08, LULC09, LULC15, ASILUFC5, and ASILUFC51
• Lightweight construction at 0.3 pounds for easy handling during installation
• Sold as a single unit with a minimum order quantity of one

Compatibility

Compatible with the following modules: ASILUFC5, ASILUFC51, LUFC00, LUFDA01, LUFDA10, LUFDH11, LUFN, LUFV2, LUFW10, LULC031, LULC033, LULC07, LULC08, LULC09, and LULC15.

Installation Notes

Installation should be performed by a licensed electrician. Disconnect and lock out all power to the motor control circuit before removing or installing any starter components, following applicable NEC lockout/tagout requirements. Verify module compatibility with the base unit before installation and consult the manufacturer documentation for proper seating and connection procedures. Do not force the control unit into position; proper alignment with the base is required for secure engagement.
