Schneider Electric LUCB12FU Starter Control Unit

Product Description

The SCHNEIDER ELECTRIC LUCB12FU is a starter control unit designed to interface with compatible soft starter and motor control modules. It serves as the command and control interface within a motor starter assembly, translating control signals into starter switching actions. The LUCB12FU is compact at 3.1 inches in length, 2.1 inches in width, and 4.1 inches in height, and weighs 0.32 pounds. It is intended for installation by licensed electricians and industrial controls technicians working on motor control assemblies in commercial or light industrial applications.

This control unit is applied in motor starter systems where a dedicated control module is needed to coordinate starter operation. Typical installations include motor control centers, panel-mounted soft starter configurations, and packaged drive assemblies. The LUCB12FU is specified for use with the following compatible modules: LUFC00, LUFDA01, LUFDA10, LUFDH11, LUFN, LUFV2, and LUFW10. It is suited for both replacement and new-build applications where SCHNEIDER ELECTRIC starter accessories are in use.

Key Features

• Starter accessory type: control unit for direct integration with compatible LUF-series modules
• Compact form factor: 3.1 x 2.1 x 4.1 inches for panel and enclosure mounting
• Lightweight construction at 0.32 pounds
• Verified compatible with seven LUF-series modules: LUFC00, LUFDA01, LUFDA10, LUFDH11, LUFN, LUFV2, LUFW10
• Sold as a single unit, consistent with standard replacement and service quantities

Compatibility

Designed for use with LUFC00, LUFDA01, LUFDA10, LUFDH11, LUFN, LUFV2, and LUFW10 starter modules as specified by the manufacturer.

Installation Notes

Installation should be performed by a qualified electrician in accordance with applicable NEC requirements and local codes. Disconnect and lock out all power to the motor control assembly before removing or installing any starter components. Verify module compatibility against the existing starter assembly before installation. Do not force the control unit into position; proper alignment with the mating connector is required before securing the assembly.
