Schneider Electric LUCB05FU Starter Control Unit

Product Description

The SCHNEIDER ELECTRIC LUCB05FU is a starter control unit designed as a direct accessory for compatible motor starter function modules. It provides the control interface between the operator and the motor starter assembly, allowing technicians to configure, monitor, and manage starter operations within a control panel. The LUCB05FU measures 4 inches in length, 3.1 inches in width, and 2.2 inches in height, and weighs 0.3 pounds. Licensed electricians and industrial controls technicians are the primary installers of this component in motor control center (MCC) and panel-mounted applications.

The LUCB05FU is suited for use in commercial and industrial electrical control applications where modular motor starters require a dedicated control unit. It is engineered to work with the LUFC00, LUFDA01, LUFDA10, LUFDH11, LUFN, LUFV2, and LUFW10 function modules, making it a targeted replacement or expansion component in existing Schneider Electric motor starter assemblies. Typical installations are found in manufacturing facilities, mechanical rooms, and process control environments where motor starter systems are panel-mounted.

Key Features

• Serves as the control unit interface for compatible LUFC00, LUFDA01, LUFDA10, LUFDH11, LUFN, LUFV2, and LUFW10 function modules
• Compact form factor: 4 inches long, 3.1 inches wide, 2.2 inches tall
• Lightweight at 0.3 pounds, supporting straightforward panel installation
• Sold individually (package quantity of 1) for single-unit replacement or add-on use
• Classified as a starter accessory for modular motor starter systems

Compatibility

The LUCB05FU is compatible with the following Schneider Electric function modules: LUFC00, LUFDA01, LUFDA10, LUFDH11, LUFN, LUFV2, and LUFW10.

Installation Notes

Installation should be performed by a licensed electrician familiar with motor control equipment and applicable NEC requirements. De-energize and lock out the control panel before handling or replacing the control unit. Verify compatibility with the installed function module before installation. Follow the manufacturer wiring diagrams and torque specifications provided in the product documentation for secure terminal connections.
