Schneider Electric LUCA1XFU Starter Control Unit

Product Description

The SCHNEIDER ELECTRIC LUCA1XFU is a starter control unit designed to interface with compatible motor starter assemblies. It serves as the control logic component within a motor starter circuit, managing the command and protection functions required for reliable motor operation. Electricians and industrial maintenance technicians install this unit as part of a modular starter assembly. At 0.27 pounds and compact dimensions of 3.4 inches by 2.1 inches by 3.2 inches, the LUCA1XFU is engineered for panel-mount applications where space efficiency matters.

The LUCA1XFU is intended for use in industrial and commercial electrical panels and motor control centers. It is designed as an accessory-class control unit, fitting into modular starter configurations for low-voltage motor control applications. This part is sold individually and suits single-unit replacement or new-build panel installations where modular starter components are specified.

Key Features

• Modular starter control unit designed for integration with compatible starter bases and function modules
• Compact form factor: 3.4 inches height, 2.1 inches width, 3.2 inches length
• Lightweight construction at 0.27 pounds for easy panel installation
• Compatible with LUFC00 and LUFN function modules as specified by the manufacturer
• Sold as a single-unit package suitable for direct replacement or new installation

Compatibility

The LUCA1XFU is designed for use with the LUFC00 and LUFN function modules, as specified in the manufacturer product data.

Installation Notes

Installation of the LUCA1XFU should be performed by a licensed electrician familiar with motor control equipment and applicable NEC requirements. De-energize and lock out the panel and all associated circuits before handling any starter components. Follow the manufacturer wiring diagram and torque requirements provided in the product documentation. Verify module seating and mechanical engagement before restoring power.
