Schneider Electric LUCA12B Starter Control Unit

Product Description

The SCHNEIDER ELECTRIC LUCA12B is a starter control unit designed for use in motor control applications. It serves as an accessory component within a larger starter assembly, providing the control interface needed to manage motor starting and stopping sequences. Electricians and industrial maintenance technicians install this unit as part of a complete motor starter configuration. At 0.31 pounds and compact in size, the LUCA12B is straightforward to integrate into panel or enclosure installations where space and weight are considerations.

The LUCA12B is suited for commercial and industrial motor control installations where a dedicated control unit is required to complete a starter assembly. It is specifically listed for use with LUFC00 and LUFN components, making it a direct-fit accessory in those configurations. Licensed electricians performing motor control center work or panel upgrades will typically encounter this unit in new installations and service replacements alike.

Key Features

• Designed as a control unit accessory for compatible Schneider Electric starter assemblies
• Compact form factor at 4.1 inches height, 2.2 inches width, and 3.1 inches length
• Lightweight at 0.31 pounds for easy handling during panel installation
• Sold individually — package quantity of one per order
• Direct-fit accessory for LUFC00 and LUFN components

Compatibility

The LUCA12B is specified for use with LUFC00 and LUFN starter components as stated by the manufacturer.

Installation Notes

Installation of this starter control unit should be performed by a qualified electrician in accordance with the National Electrical Code (NEC) and any applicable local codes. Disconnect and lock out all power to the motor control circuit before handling or installing this component. Verify that the control unit is fully seated and secured within the starter assembly before restoring power. Do not energize the circuit until all connections have been inspected and confirmed correct.
