Schneider Electric LP1K0901BD3 Iec Contactor 3 Pole 24V

Product Description

The SCHNEIDER ELECTRIC LP1K0901BD3 is a 3-pole IEC contactor with a 24-volt DC coil designed for non-reversible motor control and load switching applications. It features a normally closed (NC) auxiliary contact configuration, making it suitable for interlocking and control circuit functions. The unit measures 1.9 inches in height, 2.4 inches in width, and 2.6 inches in depth, offering a compact footprint for panel installations. Licensed electricians and industrial controls technicians install this contactor in motor control centers, distribution panels, and automated equipment enclosures where IEC-rated switching devices are required.

This contactor is suited for light industrial and commercial applications where IEC 60947-compliant switching is specified. Its non-reversible design is appropriate for single-direction motor loads, HVAC equipment, pumps, compressors, and conveyor systems. The 24 VDC coil voltage is compatible with low-voltage control circuits commonly found in PLC-driven and relay-logic control panels. Panel builders and maintenance electricians working on IEC-standard equipment will find the LP1K0901BD3 a direct replacement for same-class contactors in existing control assemblies.

Key Features

• 3-pole configuration for three-phase load switching
• 24-volt DC coil voltage for low-voltage control circuit integration
• Normally closed (NC) auxiliary contact for interlocking and status signaling
• Non-reversible action for single-direction motor and load control
• Compact body: 1.9 inches tall, 2.4 inches wide, 2.6 inches deep
• Meets multiple international standards including IEC 60947, UL Listed, CSA, RoHS Compliant, and VDE 0660

Compatibility

Designed as an OEM-style replacement for IEC-rated 3-pole contactors with 24-volt DC coil voltage and NC auxiliary contact configurations in standard industrial control panel applications.

Installation Notes

Installation should be performed by a qualified electrician in accordance with NEC requirements and local codes. De-energize and lock out all power to the control panel before removing or installing the contactor. Verify coil voltage and pole rating match the circuit requirements before energizing. Secure all terminal connections firmly and confirm auxiliary contact wiring matches the intended control logic before returning the panel to service.
