Schneider Electric LC2K0901B7 Iec Reversible Contactor

Product Description

The SCHNEIDER ELECTRIC LC2K0901B7 is a 3-pole IEC reversible contactor designed for motor control and load switching applications in industrial and commercial electrical systems. It operates on a 24-volt AC coil at 50/60 Hz and features a normally closed (NC) auxiliary contact configuration. The reversible design allows forward and reverse motor control from a single unit, eliminating the need for two separate contactors wired in opposition. Licensed electricians and industrial maintenance technicians typically install and service this device. It carries multiple international certifications and is built to IEC 60947 standards.

This contactor fits into motor starter assemblies, reversing starter panels, and machine control enclosures where direction control of three-phase motors is required. It is suited for both new construction and retrofit applications in light industrial, HVAC mechanical rooms, and process equipment installations. The 24-volt AC coil makes it compatible with low-voltage control circuits commonly used in building automation and machine control wiring schemes.

Key Features

• Reversible configuration supports forward and reverse motor direction control in a single device
• 3-pole design for three-phase load switching
• 24-volt AC coil rated for 50/60 Hz control circuits
• Normally closed (NC) auxiliary contact included
• Certified to IEC 60947, UL, CSA, VDE 0660, BS 5424, NF C 63-110, and RoHS Compliant
• Compact footprint at 90 mm wide, 58 mm tall, and 57 mm deep

Compatibility

Designed as an OEM-style replacement or new-installation contactor for IEC-rated motor control and reversing starter assemblies requiring a 3-pole, 24-volt AC coil contactor with NC auxiliary contact.

Installation Notes

Installation must be performed by a qualified electrician in accordance with the NEC and applicable local electrical codes. De-energize and lock out the panel or control enclosure before mounting or wiring this contactor. Verify coil voltage at the control circuit matches the 24-volt AC rating before applying power. Do not bypass or defeat the auxiliary contact interlocking in reversing starter configurations.
