Schneider Electric LC2K0601F7 Iec Contactor 3 Pole 6A

Product Description

The SCHNEIDER ELECTRIC LC2K0601F7 is a 3-pole IEC contactor rated for 6 amps at 440 volts AC, designed for reversible motor control applications. It features a normally closed (NC) auxiliary contact configuration and operates on a 110 volt AC coil at 50/60 Hz. This contactor is built to IEC 60947 standards and carries UL Listed, CSA, RoHS, VDE 0660, BS 5424, and NF C 63-110 certifications. Licensed electricians and industrial maintenance technicians install this type of device in motor starter panels, reversing drive circuits, and automated equipment control systems where reliable switching and directional motor control are required.

This contactor is suited for light-duty three-phase motor control in both commercial and industrial settings. Its reversible action makes it appropriate for applications where forward and reverse motor operation must be managed from a single contactor assembly. Typical installations include conveyor systems, pump stations, compressor controls, and other three-phase motor-driven equipment operating on 440 volt AC power systems with 110 volt AC control circuits.

Key Features

• 3-pole configuration supports three-phase motor control circuits
• Reversible action allows forward and reverse motor operation
• NC auxiliary contact included for interlock and control wiring
• 110 volt AC coil rated for 50 and 60 Hz power systems
• Meets IEC 60947, UL Listed, CSA, VDE 0660, BS 5424, NF C 63-110, and RoHS requirements
• Compact form factor at 3.6 inches tall, 2.5 inches wide, and 2.3 inches deep

Compatibility

Designed as an OEM-style IEC contactor replacement for three-phase motor control panels and reversing starter assemblies requiring a 3-pole, 6A, 110 volt AC coil device with NC auxiliary contact.

Installation Notes

Installation should be performed by a licensed electrician in accordance with NEC requirements and applicable local codes. De-energize and lock out all power to the panel before removing or installing the contactor. Verify coil voltage, pole rating, and auxiliary contact configuration match the existing circuit design before energizing. Secure all terminal connections to manufacturer torque specifications listed on the device label.
