Schneider Electric LC2D32F7 Iec Reversible Contactor 32A

Product Description

The SCHNEIDER ELECTRIC LC2D32F7 is a 3-pole IEC reversible contactor rated at 32 amps at 440VAC, designed for motor control and load-switching applications in industrial and commercial electrical systems. It operates on a 110VAC coil at 50/60 Hz and includes both a normally closed (NC) and normally open (NO) auxiliary contact configuration. The reversible design allows forward and reverse motor direction control within a single contactor assembly. Licensed electricians and industrial maintenance technicians are the primary installers. The unit conforms to EN/IEC 60947-4-1 and is UL Listed, making it suitable for installations requiring recognized safety certifications.

The LC2D32F7 is suited for three-phase motor starters, reversing drive circuits, and general-purpose switching in commercial and light industrial panel builds. Its reversible action makes it a fit for conveyor systems, pump controls, and other applications requiring bidirectional motor operation. The contactor is applicable in both new construction and retrofit scenarios where IEC-style components are specified. It is typically mounted on DIN rail or back-panel inside a motor control center or enclosed starter assembly.

Key Features

• 3-pole configuration with NC and NO auxiliary contacts for reversing motor control circuits
• 32A rating at 440VAC supports standard three-phase motor loads
• 110VAC coil at 50/60 Hz compatible with common control circuit voltages
• Reversible action enables forward and reverse motor direction from a single device
• Meets EN/IEC 60947-4-1, UL 508, CSA C22.2 No. 14, RoHS, and multiple international standards
• Compact footprint at 4.5 inches wide, 4.5 inches tall, and 5.3 inches deep

Compatibility

Designed as an OEM-style IEC reversible contactor replacement for three-phase motor control applications requiring a 3-pole, 32A, 110VAC coil device with NC and NO auxiliary contacts.

Installation Notes

Installation should be performed by a licensed electrician in accordance with NEC and applicable local electrical codes. De-energize and lock out the panel before mounting or wiring the contactor. Verify coil voltage matches the control circuit before energizing. Do not exceed the rated amperage or apply voltages outside the specified coil rating.
