Schneider Electric LC2D09G7V Iec Contactor 3 Pole 9A

Product Description

The SCHNEIDER ELECTRIC LC2D09G7V is a 3-pole IEC reversing contactor designed for controlling AC motors in industrial and commercial electrical installations. Rated at 9 amps at 440 volts AC, it operates on a 120-volt AC coil at 50 or 60 Hz, making it compatible with standard North American control circuits. The contactor ships configured for reversing duty and includes both a normally closed and a normally open auxiliary contact. It is installed by licensed electricians and industrial maintenance technicians in motor control centers, control panels, and machinery enclosures where reversible motor operation is required.

The LC2D09G7V is suited for reversible motor starter applications in light industrial and commercial settings. Typical installations include conveyor drives, pump systems, compressor controls, and other three-phase motor loads where forward-and-reverse operation is needed. The contactor meets a broad set of international standards, making it appropriate for domestic and export equipment builds. Its compact footprint fits standard DIN-rail or panel-mount assemblies without requiring significant cabinet space.

Key Features

• 3-pole reversing configuration for forward-and-reverse motor control
• 9-amp rating at 440 volts AC for light industrial motor loads
• 120-volt AC coil at 50/60 Hz suits standard North American control voltage
• Includes both NC and NO auxiliary contacts for interlocking and status signaling
• Certified to UL 508, CSA C22.2 No. 14, EN/IEC 60947-4-1, and additional international standards including CCC, DNV, GOST, and RoHS Compliant
• Compact body measuring 4.6 inches tall, 3.7 inches wide, and 5.5 inches deep

Compatibility

Designed as an OEM-style IEC reversing contactor for use in three-phase motor control circuits requiring a 3-pole, 9-amp, 120-volt AC coil device conforming to EN/IEC 60947-4-1 standards.

Installation Notes

Installation must be performed by a qualified electrician in accordance with NFPA 70 (NEC) and all applicable local codes. De-energize and lock out the control panel before removing or installing the contactor. Verify coil voltage matches the control circuit supply before energizing. Mechanical and electrical interlocking between forward and reverse contactors must be confirmed before returning the circuit to service.
