Schneider Electric LA4DT0U Contactor Timer Module

Product Description

The SCHNEIDER ELECTRIC LA4DT0U is a contactor timer module designed to add timing control functionality to compatible TeSys D series contactors. It mounts directly onto the contactor body as an accessory, enabling delayed or timed operation without additional external timers or relay wiring. At 0.11 pounds and compact dimensions of 2 inches by 1.9 inches by 1.6 inches, the LA4DT0U is a space-efficient solution for panel builders and industrial electricians integrating time-delay logic into motor control circuits. It is a standard replacement and upgrade component for existing TeSys D installations.

The LA4DT0U is used in motor control centers, control panels, and industrial automation applications where timed contactor operation is required. It is suited for both new panel builds and field retrofits on existing TeSys D contactor installations. Electricians and control panel technicians working on HVAC equipment, pump systems, conveyor controls, and general motor starters will find this module appropriate for adding on-delay or timing sequences directly at the contactor without expanding panel footprint.

Key Features

• Direct-mount accessory design attaches to compatible TeSys D contactors without additional hardware
• Compact form factor at 2 inches long, 1.9 inches wide, and 1.6 inches tall
• Lightweight construction at 0.11 pounds for minimal added load in panel assemblies
• Simplifies timing logic by eliminating the need for separate external timer relays
• OEM-style replacement for existing TeSys D timer module installations

Compatibility

The LA4DT0U is compatible with LC1D09-D65A contactors, LC1D80-D150 contactors, and the TeSys D contactor series.

Installation Notes

Installation should be performed by a qualified electrician in accordance with the National Electrical Code (NEC) and any applicable local codes. De-energize and lock out the panel before mounting or removing this module from the contactor. The module snaps onto the contactor accessory port and should be seated fully before restoring power. Do not attempt to modify or disassemble the module.
