Schneider Electric LA4DFB Contactor Interface Module

Product Description

The SCHNEIDER ELECTRIC LA4DFB is a contactor interface module designed for use in industrial motor control and power switching applications. It serves as an accessory that integrates with compatible TeSys D series contactors, providing the electrical interface needed to connect control signals to the contactor coil circuit. Weighing just 0.12 pounds and measuring 2 inches in length, 1.9 inches in width, and 1.6 inches in height, this compact module fits within tight panel layouts without requiring additional hardware modifications. Licensed electricians and industrial controls technicians are the primary installers of this component.

This interface module is intended for use in industrial and commercial electrical panels, motor control centers, and automation enclosures where TeSys D series contactors are deployed. It is compatible with LC1D09-D150 and TeSys D contactors, making it a direct accessory for that product family. Typical installations involve integrating PLC output signals or control circuit wiring into the contactor assembly, where the module provides a standardized electrical handoff point.

Key Features

• Designed specifically for use with LC1D09-D150 and TeSys D series contactors
• Compact form factor: 2 inches x 1.9 inches x 1.6 inches for space-constrained panel installations
• Lightweight at 0.12 pounds, minimizing load on DIN rail or panel mounting surfaces
• Contactor accessory type: interface module for signal and control circuit integration
• Sold as an individual unit (package quantity of 1)

Compatibility

Designed for use with LC1D09-D150 and TeSys D series contactors as stated by the manufacturer.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and any applicable local codes. De-energize the panel and verify absence of voltage before handling or connecting this module. Ensure the contactor is the correct model within the LC1D09-D150 or TeSys D family before installation. Follow the manufacturer wiring diagram for proper control circuit connections to avoid damage to the module or the contactor coil.
