Schneider Electric 9001SKT35 Indicating Light 24V 28V

Product Description

The SCHNEIDER ELECTRIC 9001SKT35 is a press-to-test indicating light designed for panel-mounted status and signal applications in industrial and commercial control systems. Rated for 24V and 28V operation, this unit features a round lens and screw clamp connector for reliable, tool-assisted wiring termination. The press-to-test function allows technicians to verify lamp and circuit operation without energizing the full system. Built to resist corrosion, dust, and oil exposure, the 9001SKT35 is suited for demanding environments where control panels are exposed to moisture, particulates, or lubricants. Electricians and industrial maintenance technicians are the primary installers.

This indicating light is intended for use in industrial control panels, machine operator stations, and process equipment enclosures where visual status indication is required. The 30mm panel cutout diameter is a standard industrial format, making this unit compatible with common panel mounting configurations. The multi-NEMA-rated construction covers indoor and outdoor enclosures including NEMA 1, 2, 3, 3R, 4, 4X, 6, 12, and 13 classifications, supporting a wide range of installation environments from light-duty indoor panels to washdown and submersion-rated enclosures.

Key Features

• Press-to-test function allows lamp and circuit verification without full system energization
• Rated for 24V and 28V operation to suit common low-voltage control circuits
• Screw clamp connector provides secure, vibration-resistant wiring termination
• Round lens with corrosion, dust, and oil resistance for harsh environment service
• 30mm panel cutout diameter matches standard industrial pilot device mounting
• NEMA 1/2/3/3R/4/4X/6/12/13 rated for broad enclosure compatibility

Compatibility

Designed as an OEM-style replacement or direct-fit indicating light for 30mm industrial control panel cutouts meeting NEMA 1, 2, 3, 3R, 4, 4X, 6, 12, and 13 enclosure standards. Listed under UL File E42259 CCN NKCR and CSA LR25490 Class 3211 03.

Installation Notes

Installation should be performed by a qualified electrician in accordance with the National Electrical Code (NEC) and applicable local codes. De-energize and lock out the control panel before mounting or wiring the indicating light. Screw clamp terminals require a small flat-blade screwdriver for conductor termination. Verify the supply voltage matches the 24V or 28V rating of the unit before energizing.
