Schneider Electric 9001SKR24R Push-button Switch Momentary Red

Product Description

The SCHNEIDER ELECTRIC 9001SKR24R is a momentary push-button switch operator designed for industrial control panel applications. Featuring a 30 mm mounting hole diameter and an extended straight-button profile in red, this operator provides a tactile, momentary (MO) actuation that returns to its neutral position upon release. It carries NEMA ratings of 1, 2, 3, 3R, 4, 4X, 6, 12, and 13, making it suitable for use in environments ranging from standard indoor panels to wet, oily, and corrosive locations. Electricians and control panel technicians install this type of operator as part of assembled pushbutton station configurations.

This push-button switch operator is used in residential, commercial, and industrial control panel assemblies where a standard 30 mm operator hole is required. Typical applications include motor control centers, machine control stations, and enclosure-mounted operator interfaces. The red color designation conventionally signals stop, off, or emergency functions in control wiring layouts. Its NEMA 4X rating makes it appropriate for wash-down and corrosive-environment panels commonly found in food processing, water treatment, and outdoor industrial installations.

Key Features

• 30 mm mounting hole diameter fits standard 30 mm operator cutouts
• Momentary (MO) operation returns button to neutral position on release
• Extended straight-button profile for positive tactile feedback
• Red operator color for conventional stop or off function identification
• NEMA 1, 2, 3, 3R, 4, 4X, 6, 12, and 13 rated for broad environmental coverage
• Lightweight at 0.15 pounds for easy panel integration

Compatibility

Designed as an OEM-style replacement or new-installation operator for 30 mm push-button station assemblies requiring a momentary red extended operator.

Installation Notes

Installation should be performed by a qualified electrician in accordance with the National Electrical Code (NEC) and applicable local codes. De-energize and lock out the control panel before removing or installing any push-button operator. Verify that the panel enclosure NEMA rating matches or exceeds the environmental requirements of the installation site. Do not over-torque the operator mounting nut, as this can crack the bezel or distort the enclosure cutout.
