Schneider Electric 9001SKR1GH13 Push-button Switch 600V

Product Description

The SCHNEIDER ELECTRIC 9001SKR1GH13 is a momentary push-button switch rated for 600 volts AC and 10 amps, designed for use in industrial and commercial control panels. It features a flush-style, octagon-shaped green plastic button and a 30 mm mounting hole diameter. The switch provides both normally closed (NC) and normally open (NO) contact configurations, making it adaptable to a wide range of control circuit applications. Licensed electricians and industrial maintenance technicians are the primary installers of this component in machine control, process equipment, and operator interface assemblies.

This push-button switch is suited for industrial control enclosures and panel-mount applications where a momentary operator input is required. The green button color conventionally signals start or run functions in control circuit layouts. With NEMA ratings covering Types 1, 2, 3, 3R, 4, 4X, 12, and 13, it is appropriate for both indoor and outdoor enclosures, including washdown and corrosion-resistant environments. The 30 mm mounting hole diameter is a standard size common across industrial operator interface hardware.

Key Features

• Momentary (MO) operation with NC/NO contact configuration for flexible control circuit wiring
• 600V AC voltage rating at 10 amps supports standard industrial control circuit demands
• Flush-mount, octagon-shaped green plastic button for conventional start-function identification
• 30 mm mounting hole diameter fits standard industrial panel cutouts
• NEMA Types 1, 2, 3, 3R, 4, 4X, 12, and 13 ratings for broad enclosure compatibility
• Meets multiple international standards including UL 508, CSA C22.2 No. 14, and EN/IEC 60947 series

Compatibility

Designed as an OEM-style replacement or direct-install push-button switch for 30 mm industrial control panel operator stations requiring a momentary green flush-button operator.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the NEC and applicable local codes. De-energize and lockout/tagout the control panel before mounting or wiring the switch. Verify the mounting hole is 30 mm and that enclosure rating requirements match the NEMA type needed for the environment. Confirm contact configuration wiring to NC or NO terminals matches the intended control circuit logic before restoring power.
