Schneider Electric 9001SK1L1 Illuminated Push-button Switch

Product Description

The SCHNEIDER ELECTRIC 9001SK1L1 is an illuminated momentary push-button switch designed for industrial control panel applications. It features a 30mm (1.18 inches) mounting hole diameter and an extended, straight round operator profile. The momentary (MO) action means the switch activates only while pressed and returns to its default state upon release. Rated for both AC-15 and DC-13 utilization categories, this switch is built to handle inductive load switching common in motor starter and contactor control circuits. Licensed electricians and control panel builders install this switch as part of operator interface stations.

This push-button switch is suited for use in industrial and commercial control enclosures requiring a sealed, robust operator interface. Its NEMA 4X rating makes it appropriate for washdown and outdoor environments where moisture and dust ingress are concerns. The illuminated operator provides visual status feedback to equipment operators, which is standard practice in production floor and mechanical room panel installations. Typical applications include motor control centers, machine tool panels, and HVAC equipment control stations.

Key Features

• Illuminated operator provides visual confirmation at the panel face
• Momentary (MO) action — activates on press, resets on release
• 30mm (1.18 inches) mounting hole diameter fits standard 30mm cutouts
• Extended (straight) round push-button operator style
• NEMA 1, 2, 3, 3R, 4, 4X, 6, 12, and 13 enclosure ratings
• CE, CSA, and UL Listed certifications for broad compliance

Compatibility

Designed as an OEM-style replacement or direct-install push-button switch for industrial control panels and operator stations requiring a standard 30mm momentary illuminated operator.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and applicable local codes. Disconnect and lock out all power to the control panel before removing or installing the switch. Use a standard 30mm punch or existing 30mm cutout for mounting. Verify that the operator illumination voltage matches the circuit supply before energizing the panel.
