Schneider Electric 9001KS63FB 3 Position Momentary Selector Switch

Product Description

The SCHNEIDER ELECTRIC 9001KS63FB is a 3-position momentary selector switch operator designed for industrial and commercial control panel applications. This unit ships as the switch operator only, with no contact blocks included, and mounts through a 30mm panel hole. The chrome-finished, octagonal metal bezel provides a robust, professional appearance while the momentary operation returns the handle to center when released. Rated IP66 for ingress protection, it resists dust intrusion and water jets, making it suitable for demanding environments. Electricians and control panel builders install this type of operator as part of a modular push-button station assembly.

This selector switch operator is suited for use in industrial machinery, process control panels, and equipment control stations where a 3-position momentary input is required. NEMA ratings of 1, 2, 3, 3R, 4, 12, and 13 cover a wide range of enclosure types from general-purpose indoor use through outdoor and oil-tight applications. The shock-resistant and vibration-resistant construction supports installations in environments with mechanical stress such as production floors and pump skids.

Key Features

• 3-position momentary operation — handle returns to center when released
• Chrome octagonal metal bezel with 30mm panel mount cutout
• IP66 ingress protection rating — dust-tight and resistant to water jets
• NEMA ratings 1, 2, 3, 3R, 4, 12, and 13 for versatile enclosure compatibility
• Shock-resistant and vibration-resistant construction for industrial environments
• Operator only — contact blocks sold separately, allowing custom circuit configuration
• Compliant with UL 508, CSA C22.2 No. 14, RoHS, and multiple IEC and JIS standards

Compatibility

Designed as an OEM-style operator for 30mm modular selector switch assemblies requiring a 3-position momentary handle operator. Compatible contact blocks and bases must be sourced separately to complete the switching assembly.

Installation Notes

Installation should be performed by a qualified electrician in accordance with NEC requirements and the specific enclosure rating requirements of the application. De-energize all circuits and lock out the panel before installing or replacing any control operator. The 30mm mounting hole must be clean and within tolerance to achieve the rated IP66 seal. Contact blocks are not included and must be ordered and assembled separately before the unit is placed into service.
