Schneider Electric 9001KS12K3 Selector Switch 2 Position

Product Description

The SCHNEIDER ELECTRIC 9001KS12K3 is a 2-position maintained selector switch designed for panel-mount installation in industrial and commercial control applications. It features a black knob operator and is rated for 600 volts, making it suitable for demanding control circuit environments. The maintained operation type means the switch holds its selected position until manually moved, unlike a momentary operator. The chrome metal bezel and robust enclosure ratings make this switch suitable for environments where dust, oil, and weather exposure are concerns. Licensed electricians and industrial maintenance technicians typically install and wire this component into motor control panels, machine control circuits, and similar applications.

This selector switch is intended for panel-mount applications where a 1.18-inch (30 mm) mounting hole is required. Its NEMA ratings of 1, 2, 3, 3R, 4, 6, 12, and 13 qualify it for use in a wide range of enclosure types, from general-purpose indoor panels to oil-tight and weatherproof enclosures. It is appropriate for both light commercial and heavy industrial settings where reliable manual selector control is needed. The switch ships without contact blocks, so contact block modules must be sourced and installed separately based on the specific control circuit requirements.

Key Features

• 2-position maintained operation holds switch position without continuous operator force
• 600V rating supports use in standard industrial control voltage environments
• Black knob operator with chrome metal bezel for clear visual identification and durability
• Panel mount design fits standard 30 mm (1.18-inch) mounting hole
• NEMA 1, 2, 3, 3R, 4, 6, 12, and 13 ratings cover dust-resistant, oil-resistant, and weatherproof enclosures
• CE, CSA, and UL listed certifications (UL File E42259, CSA LR24590 Class 3211 03)

Compatibility

Designed as an OEM-style panel-mount selector switch operator for use with compatible 30 mm control station and push button assemblies. No contact blocks are included; compatible contact block modules must be added separately to complete the switching circuit.

Installation Notes

Installation should be performed by a qualified electrician in accordance with applicable NEC requirements and local codes. De-energize and lock out the control panel before mounting or wiring this switch. The panel cutout must match the 1.18-inch (30 mm) hole diameter specification. Because no contact blocks are included with this operator, verify contact block compatibility before completing the assembly.
