Schneider Electric 9001KR9P38RH13 Push-button Switch

Product Description

The SCHNEIDER ELECTRIC 9001KR9P38RH13 is a maintained-action industrial push-button switch rated for 600 volts AC and 10 amps. It features a 30 mm mounting hole diameter and an extended (straight) red push button. The contact configuration is NC/NO, meaning one normally closed and one normally open contact are available in a single unit. This switch is designed for panel-mount applications in industrial and commercial control systems. Licensed electricians and industrial maintenance technicians typically install this type of switch in motor control panels, machinery enclosures, and process control stations.

This push-button switch is suited for use in industrial control panels, machine tool enclosures, and automation equipment requiring a maintained-action operator. The red extended button provides clear visual identification for stop, emergency, or mode-selection functions. Its NEMA ratings cover a wide range of environments, including indoor, outdoor, and watertight applications. The NC/NO contact configuration allows flexibility for both interlock and activation circuits within the same device.

Key Features

• Maintained (MA) operation — switch holds position after actuation, no spring return
• NC/NO contact configuration provides both a normally closed and normally open circuit in one unit
• 600V AC rating at 10 amps suitable for heavy-duty industrial control circuits
• Red extended (straight) push button for clear operator identification
• 30 mm mounting hole diameter fits standard 30 mm panel cutouts
• NEMA 1, 2, 3, 3R, 4, 6, 12, and 13 ratings for broad environmental suitability

Compatibility

Designed as an OEM-style replacement or new-installation push-button switch for industrial control panels using standard 30 mm mounting hole cutouts.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and applicable local codes. De-energize and lock out the control panel before removing an existing switch or wiring a new one. Verify the panel cutout is 30 mm before mounting, and confirm that the circuit voltage and amperage do not exceed the switch ratings. Secure the switch body with the provided hardware before making wire terminations.
