Schneider Electric 9001KR9P35RH13 Push-button Switch

Product Description

The SCHNEIDER ELECTRIC 9001KR9P35RH13 is a maintained-action push-button switch designed for industrial control panel applications. It features a 30 mm mounting hole diameter, a red extended (straight) push button, and a dual NC/NO contact configuration rated at 600 volts AC and 10 amps. The maintained (MA) operation type means the switch holds its actuated position until pressed again, making it suitable for motor start/stop circuits, control station interlocks, and similar sustained-command applications. Electricians and control panel technicians are the primary installers of this device.

This push-button switch is built for use in industrial and commercial control stations, operator interface panels, and machine control enclosures. Its NEMA ratings of 1, 2, 3, 3R, 4, 6, 12, and 13 cover a wide range of indoor and outdoor enclosure environments, including oil-tight and watertight installations. The red button color is a common visual indicator for stop or emergency-stop functions in panel layouts, though specific function assignment depends on the panel design and applicable control standards.

Key Features

• Maintained (MA) operation holds switch state after actuation — no continuous operator input required
• 30 mm mounting hole diameter fits standard 30 mm cutouts in control panels and operator stations
• Dual NC/NO contact configuration supports both normally closed and normally open circuit connections
• 600VAC rating at 10 amps suitable for industrial control voltage applications
• Red extended (straight) actuator provides clear visual identification and positive tactile engagement
• NEMA 1, 2, 3, 3R, 4, 6, 12, and 13 ratings cover a broad range of enclosure environment requirements

Compatibility

Designed as an OEM-style replacement or new-installation push-button switch for industrial control panels and operator stations using standard 30 mm mounting hole configurations.

Installation Notes

Installation should be performed by a licensed electrician in accordance with applicable NEC requirements and local codes. De-energize and lock out the control panel before mounting or wiring the switch. Verify contact configuration (NC/NO) matches the intended circuit logic before final wiring. Ensure the enclosure NEMA rating meets the requirements of the installation environment.
