Schneider Electric 9001KR4GH13 Push-button Switch 600V

Product Description

The SCHNEIDER ELECTRIC 9001KR4GH13 is a momentary push-button switch rated for 600 volts AC and 10 amps, designed for industrial control panel and machine tool applications. The switch features a green extended (straight) push button and a dual-contact configuration supporting both normally closed (NC) and normally open (NO) circuits. It mounts through a 30 mm diameter panel hole and carries NEMA ratings covering Types 1, 2, 3, 3R, 4, 6, 12, and 13 enclosures. Licensed electricians and panel builders install this switch as part of motor control, signaling, and equipment start-stop circuits.

This push-button switch is suited for residential, commercial, and light industrial control panels where a momentary contact action is required. The green button color conventionally indicates a start or run function in machine control wiring. The NEMA 4 and 6 ratings make it appropriate for washdown and wet-location enclosures in addition to standard indoor panels. The extended button profile provides positive tactile feedback in applications where operators may be wearing gloves or working in high-vibration environments.

Key Features

• Momentary (MO) operation with NC/NO dual-contact configuration
• 600 volt AC rating at 10 amps for broad control circuit compatibility
• 30 mm mounting hole diameter fits standard industrial panel cutouts
• Green extended (straight) push button for start or run function identification
• NEMA ratings 1, 2, 3, 3R, 4, 6, 12, and 13 for versatile enclosure use
• Compact footprint at 3.7 x 2.2 x 1.9 inches

Compatibility

Designed as an OEM-style replacement or new-installation push-button switch for industrial control panels requiring a standard 30 mm momentary contact device.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and applicable local codes. De-energize and lock out the control panel before removing or installing the switch. Verify that the panel enclosure NEMA rating matches or exceeds the environmental requirements of the installation site. Confirm contact configuration wiring (NC vs. NO) against the control circuit schematic before restoring power.
