Schneider Electric 9001KP35 Indicating Light 28V

Product Description

The SCHNEIDER ELECTRIC 9001KP35 is a 28-volt indicating light with a screw clamp connector, designed for use in industrial and commercial control panel applications. This pilot light provides a clear visual status indication for machine control circuits, operator interface panels, and process control systems. It carries multiple agency listings including UL, CSA, CE, and meets NEMA enclosure ratings for a wide range of indoor and outdoor environments. Electricians and industrial controls technicians install this unit as a direct replacement or new installation in pushbutton and selector switch assemblies.

This indicating light is suited for use in residential, commercial, and light industrial control enclosures rated NEMA 1, 2, 3, 3R, 4, 6, 12, and 13. Typical applications include motor control centers, machine panels, HVAC control cabinets, and process automation equipment where a reliable 28-volt lamp indicator is required. The screw clamp connector simplifies field wiring by allowing tool-assisted termination without solder or crimp tools, making it practical in both new construction and retrofit work.

Key Features

• 28-volt rated indicating light for low-voltage control circuit applications
• Screw clamp connector for secure, tool-assisted field wiring termination
• NEMA 1/2/3/3R/4/6/12/13 rated for broad environmental suitability
• UL Listed (File E42259, CCN NKCR) and CSA LR25490 Class 3211 03 certified
• CE marked for compliance with applicable European directives
• Compact form factor fits standard 30 mm control station cutouts

Compatibility

Designed as an OEM-style replacement or new-installation indicating light for industrial and commercial control panels and pushbutton stations requiring a 28-volt lamp assembly with screw clamp termination.

Installation Notes

Installation should be performed by a licensed electrician in accordance with NEC requirements and any applicable local codes. De-energize the control panel and verify the circuit is at zero voltage before removing or installing the lamp assembly. Use the screw clamp connector to secure conductors firmly, and confirm the supply voltage matches the 28-volt rating before energizing. Avoid exceeding the rated voltage, as overvoltage will shorten lamp life or damage the assembly.
