Schneider Electric 9001K3L35GH13 Illuminated Push-button Switch

Product Description

The SCHNEIDER ELECTRIC 9001K3L35GH13 is an illuminated, momentary push-button switch designed for industrial control panel applications. It features a flush-mount, octagon-shaped green metal operator with a 30 mm mounting hole diameter and supports both normally closed and normally open contact configurations. Rated at 600 volts AC and 10 amps, this switch delivers reliable switching performance in demanding environments. Licensed electricians and industrial control technicians install this switch into operator interface panels, motor control centers, and machine control enclosures.

This switch is suited for commercial and industrial installations where a clearly visible, illuminated green momentary actuator is required. The flush-mount profile keeps the operator close to the panel face, reducing accidental actuation. Its NEMA ratings cover a wide range of enclosure types, making it appropriate for both indoor and select outdoor or wet-location control panel builds. It is a direct replacement or upgrade option for existing 30 mm push-button switch assemblies in industrial automation and process control systems.

Key Features

• Illuminated green octagon flush operator for clear visual status indication
• Momentary operation with NC/NO contact configuration for flexible circuit wiring
• 600 volt AC rating at 10 amps for industrial control voltage applications
• Metal operator construction for durability in production and process environments
• NEMA 1, 2, 3, 3R, 4, 12, and 13 enclosure ratings for broad installation versatility
• Meets multiple international standards including UL 508, CSA C22.2 No. 14, and EN/IEC 60947-5-1

Compatibility

Designed as an OEM-style replacement or new-installation 30 mm push-button switch for industrial control panels and motor control enclosures requiring a momentary, illuminated green flush operator.

Installation Notes

Installation should be performed by a qualified electrician in accordance with the NEC and applicable local codes. De-energize and lock out the control panel before mounting or wiring the switch. Verify the panel enclosure NEMA rating matches the environment before installation. Do not exceed the rated voltage or amperage of the switch contacts.
