Schneider Electric 9001K3L1GH13 Push-button Switch 600V

Product Description

The SCHNEIDER ELECTRIC 9001K3L1GH13 is an illuminated, momentary push-button switch designed for industrial control panel applications. It features a flush-mounted, octagon-shaped green metal operator with a 30mm mounting hole diameter. Rated at 600 volts AC and 10 amps, it provides both normally closed and normally open contact configurations in a single unit. The metal construction and NEMA 4 enclosure rating make it suitable for demanding environments where moisture, dust, and corrosive agents are a concern. Licensed electricians and panel builders are the primary installers of this device.

This push-button switch is used in industrial and commercial control panels, machine tool enclosures, and automation systems where a momentary actuation signal is required. The illuminated green operator gives operators a clear visual status indication at the panel face. Its NEMA 1, 2, 3, 3R, 4, 12, and 13 ratings cover a broad range of indoor and outdoor installation environments. The flush button profile reduces the chance of accidental actuation in busy production settings.

Key Features

• Illuminated flush green octagon operator for clear visual panel identification
• Momentary operation with NC and NO contact configuration
• 600V AC rating at 10 amps for robust industrial circuit compatibility
• 30mm mounting hole diameter fits standard 30mm panel cutouts
• Metal push-button construction for durability in heavy-use environments
• NEMA ratings 1, 2, 3, 3R, 4, 12, and 13 for wide environmental coverage
• Certified to UL 508, CSA C22.2 No. 14, EN/IEC 60947-1, EN/IEC 60947-5-1, EN/IEC 60947-5-4, JIS C 4520, and JIS C 852

Compatibility

Designed as an OEM-style replacement or new-installation push-button operator for 30mm industrial control panel cutouts conforming to standard momentary switch mounting configurations.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and applicable local codes. De-energize and lock out the control panel before mounting or wiring this switch. Verify that the panel cutout matches the 30mm mounting hole diameter before installation. Do not exceed the rated voltage or amperage when wiring contact terminals.
