Schneider Electric 9001K2L1G Push-button Switch 600V

Product Description

The SCHNEIDER ELECTRIC 9001K2L1G is a heavy-duty momentary push-button switch rated for 600 volts and designed for industrial and commercial control panel applications. It features a 30 mm mounting hole diameter, a green extended round button, and a momentary (MO) operation type, meaning the circuit closes only while the button is depressed. The switch carries dust-tight, oiltight, and watertight resistance ratings, making it a reliable choice for demanding environments. Licensed electricians and industrial control technicians install this switch in operator interface stations, machinery control panels, and motor control enclosures where momentary start or signal inputs are required.

This switch is suited for use in both indoor and outdoor control panel installations where environmental protection is critical. Its NEMA ratings of 1, 2, 3, 3R, 4, 6, 12, and 13 cover a broad range of enclosure types, from general-purpose indoor panels to watertight and oil-resistant outdoor enclosures. The green button color is commonly used to indicate start or run functions in standard industrial control wiring conventions. Typical applications include motor starters, conveyor controls, pump control stations, and other equipment requiring a direct operator input.

Key Features

• Momentary (MO) operation — circuit active only while button is held
• 600-volt rating suitable for industrial control circuits
• 30 mm mounting hole diameter for standard 30 mm panel cutouts
• Extended round green button for clear visual identification
• Dust-tight, oiltight, and watertight construction
• NEMA 1, 2, 3, 3R, 4, 6, 12, and 13 rated enclosure compatibility
• UL Listed and CSA certified for compliance with North American standards

Compatibility

Designed as an OEM-style replacement or new-installation push-button switch for 30 mm industrial control panel stations requiring momentary green button operation at up to 600 volts.

Installation Notes

Installation should be performed by a licensed electrician in accordance with NEC requirements and applicable local codes. De-energize and lock out the control panel before mounting or wiring the switch. Verify that the enclosure NEMA rating matches the installation environment before cutting the 30 mm panel hole. Confirm circuit voltage and contact configuration requirements before completing wiring connections.
