Schneider Electric 9001K1L1 Push-button Switch 30mm Momentary

Product Description

The SCHNEIDER ELECTRIC 9001K1L1 is a momentary push-button switch designed for industrial and commercial control panel applications. It features a 30 mm mounting hole diameter, an extended straight round actuator, and screw terminal connections. The switch is rated dusttight, oiltight, and watertight, making it suitable for demanding environments where contamination and moisture exposure are a concern. It carries NEMA ratings 1, 2, 3, 3R, 4, 6, 12, and 13, and meets CE, CSA, and UL listing requirements. Electricians and control panel technicians install this switch as part of motor control circuits, machinery interlocks, and operator interface stations.

This push-button switch is suited for both residential and commercial control panel installations where a durable, momentary-action operator is required. Its weatherproof and oiltight construction makes it appropriate for washdown environments, outdoor enclosures, and machine tool panels. The momentary contact operation returns to its default state once pressure is released, which is typical in start or stop circuit functions. It is rated for AC-15 and DC-13 utilization categories, covering inductive loads in both AC and DC control circuits.

Key Features

• 30 mm mounting hole diameter for standard industrial panel cutouts
• Momentary (MO) operation with extended straight round actuator
• Dusttight, oiltight, and watertight construction for harsh environments
• NEMA ratings 1, 2, 3, 3R, 4, 6, 12, and 13
• Screw terminal connections for secure field wiring
• Rated for AC-15 and DC-13 utilization categories

Compatibility

Designed as an OEM-style replacement or new-installation push-button switch for 30 mm industrial control panel assemblies requiring a momentary round operator with dusttight, oiltight, and watertight protection.

Installation Notes

Installation should be performed by a licensed electrician in accordance with applicable NEC requirements and local codes. De-energize and lock out the control panel before removing or installing the switch. Screw terminals should be tightened to the terminal manufacturer specification using an appropriate insulated screwdriver. Verify the enclosure NEMA rating is compatible with the installation environment before finalizing the assembly.
