Schlage Commercial ND53LATH613 Nd Series Entry Lockset

Product Description

The SCHLAGE COMMERCIAL ND53LATH613 is an entry-function lockset from the ND Series, configured with the Athens lever trim and finished in Oil Rubbed Bronze (finish code 613). This unit ships less cylinder, meaning the mortise cylinder is not included and must be ordered separately to complete the locking function. The package includes a 13-247 latch and a 10-025 strike, providing a complete trim assembly ready for cylindrical lock prep. It is designed for commercial and institutional door openings where controlled entry with lever accessibility is required. Licensed locksmiths, commercial door hardware installers, and facilities maintenance technicians are the typical installers for this hardware.

The ND53LATH613 is suited for commercial interior and exterior doors in office buildings, schools, healthcare facilities, and institutional environments. The ND Series is a heavy-duty cylindrical lockset line built for high-traffic openings. The Athens lever style provides a clean, traditional profile. The Oil Rubbed Bronze finish coordinates with door hardware programs specifying dark bronze aesthetics. The less-cylinder configuration is common in projects where the specifying authority requires keying to be handled separately or where existing cylinders are being reused.

Key Features

• Entry function: outside lever locked or unlocked by cylinder; inside lever always free egress
• Less cylinder configuration allows separate cylinder specification or reuse of existing keyed cylinders
• Includes 13-247 latch and 10-025 strike for a complete trim assembly
• Athens lever trim in Oil Rubbed Bronze (613) finish
• ND Series heavy-duty cylindrical platform suited for high-traffic commercial openings
• Sold individually; case quantity of 6 available for project orders

Compatibility

Designed as an OEM-specification replacement or new-installation trim assembly for ND Series cylindrical lock chassis on standard commercial door preps. Specific chassis and cylinder compatibility should be confirmed against the ND Series product family documentation prior to ordering.

Installation Notes

Installation should be performed by a licensed locksmith or qualified commercial door hardware technician familiar with cylindrical lockset procedures. Verify door prep dimensions and backset before installation. Because this unit ships less cylinder, a compatible mortise cylinder must be sourced and installed to complete the entry function. Consult local building codes and ADA accessibility requirements when selecting and positioning lever hardware on accessible routes.

WARNING: This product can expose you to chemicals including lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
