SCHLAGE C2000-STRM-C-613-KDC storeroom cylindrical lock curved lever

Product Description

The SCHLAGE C2000-STRM-C-613-KDC is a grade 2 storeroom cylindrical lock. It features a non-clutching curved lever and a conventional cylinder design. The lock has a three-inch rose diameter and is non-handed. This model is ideal for storeroom applications and complies with ADA accessibility guidelines.

• Grade 2 storeroom cylindrical lock
• Non-clutching curved lever
• Conventional cylinder design

Product Highlights

Product Information

Standard Information

• Brand: SCHLAGE
• MPN: C2000-STRM-C-613-KDC

Technical Specifications

• Grade: ANSI/BHMA Grade 2
• Thickness: 1-3/8 inches - 1-3/4 inches
• Handing: Non-handed
• Color: Dark oxidized satin bronze oil rubbed
• Keyway: SC4 6-pin pin & tumbler
• Function: Storeroom
• Keying: Keyed different
• Cylinder Type: Conventional cylinder
• ADA Compliance: Yes
• Latch Type: Deadlatch
• Lever/Knob Design: C - Curved
• Lock Face Size: 2-1/4 inches x 1-1/8 inches
• Strike Type: ANSI curved lip
• Lock Category: Cylindrical lock
• Standards: UL listed 3-hour
• Cylinder Included: Yes
• Latch Bolt Type: Deadlatch
• Door Thickness: 1-3/8 inches - 1-3/4 inches
• Handle Type: Lever
• Finish: Oil-rubbed bronze
• Manufacturer Parent: Allegion
