Schlage B580643E Grade 2 Turn Only Deadbolt Aged Bronze

Product Description

The SCHLAGE B580643E is a Grade 2 turn-only deadbolt designed for commercial door applications where keyless single-side operation is required. The bolt is thrown and retracted by a turn unit only, with no exterior keyed cylinder - the outside face features a blank plate. This unit ships complete with a 12287 latch and 10094 strike, and is finished in Aged Bronze. It carries ANSI A156.36 certification and is built to fit doors ranging from 1-3/8 inches to 1-7/8 inches in thickness. Licensed commercial locksmiths and commercial door hardware installers are the primary trade for this product.

This deadbolt is suited for interior commercial doors - such as stairwell, storage, or utility room doors - where access control from one side is the design intent. The blank exterior plate provides a clean look while preventing outside actuation. The included 12287 latch and 10094 strike simplify the installation package. The Aged Bronze finish coordinates with standard commercial hardware finishes in office, institutional, and light industrial settings.

Key Features

• Turn-only operation - bolt thrown and retracted from interior side only, exterior face is blank plate
• Grade 2 commercial rating per ANSI A156.36
• Compatible door thickness range: 1-3/8 inches to 1-7/8 inches
• Includes 12287 latch and 10094 strike for a complete installation package
• Aged Bronze finish for coordination with standard commercial hardware sets

Compatibility

Designed as an OEM-style replacement or new-installation deadbolt for commercial doors within the 1-3/8 inch to 1-7/8 inch thickness range meeting ANSI A156.36 Grade 2 requirements.

Installation Notes

Installation should be performed by a licensed locksmith or qualified commercial door hardware technician. Verify door thickness falls within the 1-3/8 inch to 1-7/8 inch range before installation. Ensure the door is not under load and the latch and strike are properly aligned before final fastening. Refer to ANSI and local building code requirements for proper backset and strike reinforcement on commercial applications.
