Satco S29062 11.6 Watt LED Direct Wire Downlight 5-6 Inch

Product Description

The Satco S29062 is an 11.6 watt LED direct wire downlight with edge-lit technology, designed for 5-6 inch recessed lighting fixtures. This dimmable downlight operates at 120 volts and emits a 3000K warm white light with 800 lumens. It is suitable for indoor and damp locations and is lawful for sale in California.

• Dimmable
• Edge-lit design
• Suitable for damp locations

Product Highlights

This Satco LED downlight offers energy-efficient lighting with a long lifespan and dimmable functionality, ideal for residential and commercial applications.

Product Information

Standard Information

• Brand: SATCO
• Manufacturer Part Number: S29062
• Country of Origin: China

Technical Specifications

• Base: Direct Wire
• Type: Direct Wire LED Downlight
• Brand: Satco
• Shape: Circular
• Style: Contemporary
• Width: 7.13 in
• Finish: White
• Height: 1.94 Inch
• Length: 6.88 Inch
• Lumens: 800 Lumen
• Voltage: 120 Volt
• Wattage: 11.6 Watt
• Diameter: 7.13 Inch
• Dimmable?: Yes
• Lamp Type: LED
• Sub Brand: Satco
• Beam Spread: 100
• Ballast Type: Self
• Fixture Type: Round
• Power Factor: 1
• Wet Location: Damp
• Color Accuracy: 83
• Indoor Outdoor: Indoor
• Number of Lamps: 1
• Technology Type: LED
• Warranty Length: 5 yr
• Color Temperature: Warm White
• Country of Origin: China
• Average Rated Life: 40000 hr
• Color Rendering Index: 83
• Correlated Color Temp: 3000 K
• Operating Temperature: -20 degrees C
• Incandescent Equivalent: 65 W
• Catalog Number: S29062
• Manufacturer: Satco
• Made in USA: No
• Mounting: Ceiling
• UPC: 045923290626
• GTIN: 00045923290626
• Length UOM: Inch
• Width UOM: Inch
• Height UOM: Inch
• Voltage Rating: 120
• Wattage Selectable: False
• Finish Family: White
• Amps: 0.097A
• IOT Enabled: False
• Minimum Compartment Size: Diameter: 6.14 in. Height: 2.36 in.
• Product Technology: LED
• CCT (Kelvin Temp): 3000K
• Hours Rated: 40000
• Beam Angle (degree): 100
• CRI: 80+
• Dimming Type: Forward Phase or Reverse Phase or Phase Selectable or Triac
• Operating Temp: -20C (-4F) to +45C (+113F)
• Volts: 120v
• Watts: 11.6W
• Lamp Base: Integrated
• ANSI Base: Integrated
• Fixture Shape: Round
• Warranty: 5-Years
• Air Tight: True
• CA Regulations: T20 Exempt - Fixtures Not Regulated
• CA Status: Lawful for sale in California
• FCC Compliant: True
• IC Rated: True
• Location Rating: Damp
• ROHS Compliant: Yes
• Safety Listing: cULus - Classified
• CA Compliance Text: Lawful for sale
• DLC Approved: False
• Energy Star Certified: No
• Title 20: Exempt
• T24 Compliant: False
• Condition: New
• Light Color: Soft White
• Power Source: Corded-electric
• Size: 5-6"
• Special Features: Dimmable
• Bulb Shape Code: S29062
• Model: S29062
• Bulb Life Hours: 40000 Hours
• Mfg #: S29062
• Order Code: 11.6WLED/DW/EL/5-6/30K/120V
• Input Volts: 120V
• Lumens/Watt: 69
• Certifications: Damp Rated, UL
• Life (hrs): 40000
• CCT Selectable: False
