Satco S13188 LED HID ED28 34W EX39

Product Description

The SATCO S13188 is a 34W LED HID replacement lamp with an ED28 form factor. Operating within a 120V-277V range, this lamp features an extended mogul base and emits a 5000K natural light. It is designed for indoor and outdoor use, and has built-in surge protection. This LED lamp is not dimmable and is rated for enclosed fixtures.

• 34 Watt LED HID Replacement
• ED28 form factor
• Extended Mogul Base

Product Highlights

34W LED HID replacement lamp with EX39 base, suitable for both indoor and outdoor applications. Features 5000K natural light and is non-dimmable.

Product Information

Standard Information

• Brand: SATCO
• Manufacturer Part Number: S13188

Technical Specifications

• Lamp Ballast Type AB: Type B
• Ballasting Requirements: Ballast Bypass
• Lamp Filament: LED
• Material: Glass
• Fixture Type: LED HID
• Status: Active
• Style: Utility
• Surge Protection: Built-in surge protection - 4KV
• CCT Selectable: False
• Wattage Selectable: False
• Finish Family: White
• Amps: 0.280-0.120A
• Has Camera: False
• IOT Enabled: False
• Minimum Compartment Size: Length: 9.25 in. Width: 9.25 in. Height: 17.28 in.
• Operating Position: Universal
• Power Factor: 0.9
• SDS Class: LED_Lamp
• Indoor Outdoor: Indoor, Outdoor
• Product Technology: LED
• CCT (Kelvin Temp): 5000K
• Dimmable: Non-Dimmable
• Hours Rated: 50000
• Beam Angle (degree): 320
• Color Temp: Natural Light
• CRI: 80+
• Operating Frequency: 60Hz
• Operating Temp: -30C (-22F) to +65C (+149F)
• HID Equivalent: 150W
• Lumens: 5000L
• Volts: 120V-277V
• Watts: 34W
• Lamp Base: Mogul Extended
• Finish: WHITE
• Housing Color: None
• ANSI Base: EX39
• Lamp Type: ED28
• MOD Lamps: 3.54
• MOL: 8.4
• Rated For Enclosed Fixture: True
