Product Description
The SATCO S11731 is an LED T8 lamp with battery backup, operating at 17W and delivering between 2100 and 2300 lumens. This lamp features 3CCT selectable options and is designed for ballast bypass installations. It provides up to 90 minutes of illumination during power outages, making it suitable for commercial applications where backup lighting is essential.
- Features LED T8 lamps with battery backup.
- Operates at 17W with a selectable 3CCT.
- Provides between 2100-2300 lumen output.
Product Highlights
This Satco LED T8 lamp offers battery backup and selectable color temperatures for versatile lighting solutions.
Product Information
Standard Information
-
Brand: SATCO
-
Manufacturer Part Number: S11731
-
Country of Origin: China
Technical Specifications
-
Brand: Satco
-
Product UPC: 04592311731
-
12-Digit UPC: 045923117312
-
Catalog Number: S11731
-
Manufacturer: Satco
-
Color Rendering Index (CRI): 83
-
Frequency Range: 60
-
Lamp Type: T8
-
Lens Color: Frost
-
Lens Material: Polycarbonate
-
Lumens: 2100L/2300L/2200L
-
Material: Aluminum
-
Shape: T8
-
Length: 48
-
Length UOM: Inch
-
Non Hazardous Location: Damp
-
Operating Temperature: -20C (-4F) to +45C (+113F)
-
Voltage Rating: 120V-277V
-
Wattage: 17
-
Power Factor: 0.9
-
Lamp Ballast Type AB: Type B
-
Ballasting Requirements: Ballast Bypass
-
Lamp Filament: LED
-
Fixture Type: Linear
-
Status: Active
-
Style: Utility
-
Surge Protection: Built-in surge protection - 1KV
-
Total Harmonic Distortion: <25%
-
Tube Guard Use: No
-
CCT Selectable: Yes
-
Wattage Selectable: No
-
Finish Family: White
-
Additional Info: 5 Watts and 700 Lumens in Battery Backup Mode
-
Amps: 0.142-0.061A
-
Has Camera: No
-
IOT Enabled: No
-
Lens Finish: Frost
-
Nominal Length: 48.0
-
Operating Position: Horizontal
-
SDS Class: Lithium_Ion_Battery
-
Shatter Proof Type: Yes
-
Indoor Outdoor: Indoor
-
Product Technology: LED
-
Fluor Equiv: 32W
-
Incandescent Equivalent: 90W
-
CCT (Kelvin Temp): 3500K/4000K/5000K
-
Hours Rated: 50000
-
Beam Angle (degree): 140
-
Color Temp: Neutral White to Natural Light
-
CRI: 80+
-
Operating Frequency: 60Hz
-
Volts: 120V-277V
-
Watts: 17W
-
Lamp Base: Medium Bi Pin
-
Finish: WHITE
-
Housing Color: White
-
ANSI Base: G13
-
MOD Lamps: 1.13
-
MOL: 47.78
-
Rated For Enclosed Fixture: Yes
-
Light Type: LED
-
Bulb Shape Size: T8
-
Bulb Base: G13
-
Specific Uses For Product: General purpose
-
Light Color: Soft White, Cool White, Daylight
-
Voltage: 120 Volts
-
Color Temperature: 5000 Kelvin
-
Brightness: 2300 Lumen
-
Controller Type: Push Button
-
Power Source: AC
-
Power Consumption: 17 Watts
-
Light Source Type: LED
-
Light Source Wattage: 17 Watts
-
Control Method: App
-
Light Source Operating Life: 50000 Hours
-
White Brightness: 2300 Lumens
-
Efficiency: High Efficiency
-
Dimmable: No
-
Lamping Category: LED
-
Lamping Features: Bulb Angle: 140
-
Bulb Average Hours: 50000
-
Bulb Color: White
-
Bulb Color Temp: 3500K/4000K/5000K
-
Bulb Shape: T8
-
Bulb Spread: 140
-
Bulb Details: Phase cut
-
Lamping Included: Bulbs Not Included
-
Lamping Type: Medium Bi Pin LED
-
Total Number of Bulbs: 1
-
Wattage Max: 17.00
-
Diameter: 1.13
-
Width: 1.13
-
UL Ratings: cULus/cETLus Damp
-
Part Number: S11731
-
Certificate: cETLus Listed, Title 20, Title 24, RoHS Compliant, FCC, Damp Location, NSF, DLC Listed
-
Tube Length: 4 ft
-
Product Dimensions: 4-ft (L)
-
Correlated Color Temp: 3500 K
-
IP Rating: IP20
-
Technology Type: LED
-
Type: Linear
-
Wet Location: Damp
