Sandvik Coromant 7611856 Corner Radius End Mill Head

Product Description

The SANDVIK COROMANT 7611856 is a modular, solid carbide corner radius end mill head designed for precision milling operations. Part of the CoroMill 316 series, this two-flute head features an AlTiN coating for improved heat resistance and tool life at elevated cutting temperatures. The mill diameter is 1.50 mm (0.0591 inches) with a corner radius of 4.5 mm and a length of cut of 3.7 mm. It connects via a modular interface, making it compatible with the CoroMill 316 system for quick changeovers on milling machines and machining centers. Machinists and CNC operators in precision manufacturing environments are the primary users of this tooling.

This end mill head is suited for light milling, profiling, and contouring applications where small-diameter tooling is required. The two-flute spiral configuration and right-hand cutting direction are appropriate for finishing passes and detailed work on ferrous and non-ferrous materials. The modular design allows the head to be exchanged without removing the entire tool assembly from the spindle, supporting efficient production in job shop and high-volume CNC machining environments.

Key Features

• Solid carbide construction for rigidity and dimensional stability in small-diameter milling
• AlTiN coating provides heat resistance and extended tool life in high-temperature cutting conditions
• Modular connection type enables fast head changeovers within the CoroMill 316 system
• Two-flute spiral geometry suited for finishing and profiling passes
• Right-hand cutting direction for standard CNC milling setups
• Non-center-cutting design intended for peripheral and side milling, not plunge entry

Compatibility

Designed for use with the SANDVIK COROMANT CoroMill 316 modular milling system. Verify shank and interface compatibility with the specific CoroMill 316 body being used before installation.

Installation Notes

Installation should be performed by a qualified machinist or CNC tooling technician. Power down and lock out the machine spindle before mounting or removing the end mill head. Use the appropriate torque wrench and CoroMill 316 assembly tools as specified by the tooling system documentation. This head is non-center-cutting and should not be used for plunge milling.
