Sandvik Coromant 7611647 Corner Radius End Mill Head

Product Description

The SANDVIK COROMANT 7611647 is a modular corner radius end mill head engineered for precision milling applications. Built from solid carbide and coated with AlTiN for heat and wear resistance, this head is part of the CoroMill 316 series. It carries a 3.50mm (0.1378 inch) mill diameter, a 6mm corner radius, and a 7.23mm length of cut. Four spiral flutes deliver efficient chip evacuation in demanding cutting conditions. Installation requires a compatible CoroMill 316 modular connection. This head is installed by CNC machinists and toolroom professionals working with milling machines and machining centers.

The 7611647 is suited for finish milling and profiling operations in ferrous and hardened materials where corner geometry control is critical. The AlTiN coating performs well in dry or near-dry cutting environments at elevated temperatures. Its right-hand cutting direction and spiral flute geometry support consistent surface finish and tool life in high-speed applications. This head is a direct modular component and must be paired with a compatible CoroMill 316 shank or adapter. It is not center-cutting and is not designed for plunge entry.

Key Features

• Solid carbide construction for rigidity and wear resistance in demanding milling operations
• AlTiN coating provides thermal protection and extended tool life in dry cutting conditions
• 3.50mm mill diameter with a 6mm corner radius for controlled edge geometry
• 4 spiral flutes for efficient chip removal and consistent surface finish
• Modular connection compatible with CoroMill 316 system shanks and adapters
• Right-hand cutting direction; not center-cutting

Compatibility

Designed for use with the Sandvik Coromant CoroMill 316 modular tooling system. Must be paired with a compatible CoroMill 316 modular shank or adapter. Verify connection interface and diameter compatibility before installation.

Installation Notes

Installation of modular end mill heads is performed by CNC machinists or toolroom technicians. Ensure the machine spindle is fully stopped and the tool is properly secured in the modular shank before operation. Use the appropriate torque wrench or coupling tool as specified by the tooling system manufacturer for the modular interface. Do not use the head in applications requiring center-cutting or axial plunge entry, as this head is not center-cutting.
