Sandvik Coromant 5910508 Indexable Toolholder Shim

Product Description

The SANDVIK COROMANT 5910508 is a replacement shim designed for use with indexable toolholders in machining applications. Shims seat beneath the insert pocket to provide a stable, accurate seating surface for the cutting insert. Proper shim condition is critical to insert clamping integrity and dimensional consistency during turning, boring, or milling operations. This shim is configured for right-hand cutting direction and corresponds to shim style 5322 474. Each order includes one shim. Machinists and toolroom technicians install this component as part of routine insert pocket maintenance or following insert cratering damage to the shim seat.

This shim is intended for use in indexable toolholder assemblies requiring the 5322 474 shim style. It is suited for lathe turning toolholders and similar indexable insert-style cutting tool bodies used in production and job-shop machining environments. Replacement is typically performed during scheduled tooling maintenance or when the shim shows signs of deformation, pitting, or cratering that compromises insert seating. The right-hand cutting direction designation must be matched to the toolholder configuration before installation.

Key Features

• Right-hand cutting direction configuration for compatible toolholder bodies
• Shim style 5322 474 for precise fitment in designated insert pockets
• Replacement-grade component designed to restore accurate insert seating
• Individual unit packaging with a minimum order quantity of 10 units
• Manufacturer catalog number 5322 474-01 for cross-reference ordering

Compatibility

Designed as a replacement shim for SANDVIK COROMANT indexable toolholders requiring shim style 5322 474 in a right-hand cutting configuration. Verify shim style designation and cutting direction against the toolholder specification before ordering.

Installation Notes

Shim replacement should be performed by a qualified machinist or toolroom technician. Secure the toolholder in a vise or fixture and remove all clamping screws before extracting the worn shim. Inspect the pocket floor for debris or raised material before seating the new shim. Torque all clamping hardware according to the toolholder manufacturer specifications provided in the original toolholder documentation.
