Sandvik Coromant 5763471 Cap Screw Torx Plus M4

Product Description

The SANDVIK COROMANT 5763471 is a Torx Plus drive cap screw designed specifically for securing indexable inserts in cutting tool assemblies. It features an M4 thread size and is engineered to meet the precise clamping requirements of indexable tooling systems used in metal cutting and machining operations. The Torx Plus drive interface provides improved torque transfer and reduced driver wear compared to standard hex drives. This screw is a direct replacement or service fastener intended for use by machinists, toolroom technicians, and CNC setup personnel who maintain and reconfigure indexable toolholders and adapters.

This cap screw is suited for use with indexable toolholders, adapters, and related cutting tool bodies where M4 fasteners are required to retain inserts or clamp components. It applies to both roughing and finishing tooling configurations across a range of CNC and manual turning, milling, and boring applications. Industry standard number 5519 026-09 provides a reference point for cross-checking compatibility with tooling documentation and manufacturer catalogs.

Key Features

• Torx Plus drive type for increased torque transfer and reduced cam-out during insert changes
• M4 thread size for use with standard indexable toolholder clamping systems
• Designed for adapter hardware compatibility in indexable cutting tool assemblies
• Industry standard number 5519 026-09 for cross-reference and sourcing verification
• Lightweight at 0.25 pounds per package, suitable for keeping spare fasteners on-hand in toolrooms

Compatibility

Compatible with indexable toolholders and adapters requiring M4 Torx Plus cap screws. Industry standard reference number 5519 026-09 may be used to verify fitment with specific tooling bodies. Consult toolholder documentation to confirm thread engagement length and drive specification before installation.

Installation Notes

Installation should be performed by qualified toolroom personnel or CNC machinists familiar with indexable tooling systems. Ensure the toolholder or adapter is clear of the machine spindle and all moving components before replacing the screw. Use a calibrated Torx Plus driver of the correct size to avoid drive recess damage. Do not exceed the torque specification stated in the toolholder manufacturer documentation for M4 clamping screws.
