Rwc UXLBV54 2 Inch Push-to-connect Brass Ball Valve

Product Description

The RWC UXLBV54 is a full-port brass ball valve designed for use in residential and light commercial plumbing systems. It features a push-to-connect end style, allowing installation without soldering, crimping, or special tooling. The full-port design maintains maximum flow through the valve body, minimizing pressure drop across the fitting. At 2 inches nominal size, this valve suits main line shutoff, branch isolation, and service valve applications where quick, reliable shutoff is required.

This valve is suited for residential and light commercial plumbing installations where a tool-free shutoff solution is needed. Push-to-connect technology makes it a practical choice for retrofit work, tight spaces, or situations where open flame is not permitted. Licensed plumbers and pipefitters typically install this valve on copper, CPVC, and PEX tubing in potable water supply systems.

Key Features

• 2-inch nominal push-to-connect end connections — no solder or crimp required
• Full-port ball design for unrestricted flow and minimal pressure drop
• Brass body construction for durability in potable water applications
• Quarter-turn operation for fast shutoff
• Compatible with multiple tubing types including copper, CPVC, and PEX

Compatibility

Designed as an OEM-style push-to-connect replacement or new-installation ball valve for 2-inch nominal residential and light commercial potable water plumbing systems.

Installation Notes

Installation should be performed by a licensed plumber in accordance with local plumbing codes and the International Plumbing Code (IPC). Shut off the water supply and depressurize the line before installing or removing the valve. Ensure tubing ends are cut square, deburred, and fully inserted to the depth mark before engaging the push-to-connect fitting. Do not exceed the rated working pressure or temperature specified by the manufacturer.

Technical Specifications

• Nominal Size: 2 inches
• End Style: Push-to-Connect
• Port Type: Full Port
• Body Material: Brass

Standard Information

• Brand: RWC
• Manufacturer Part Number: UXLBV54
